Product Lines
Integrated Pedestrian and Vehicle Access Control
Eight product lines covering pedestrian turnstile gates and vehicle access systems — each available with OEM/ODM customization, project-specific specification, and export-ready packaging for overseas projects.
Category Grid
Two families, one supplier
Choose by entrance type. Each category page carries full specifications, applications and a live product list scoped to that line.
Within each family, products share a common control platform, which makes mixed projects simpler: readers, relay logic and access profiles behave consistently whether you combine a speed gate and a flap barrier, or a barrier gate with an LPR camera. Review the technology page for the control and integration layer behind the ranges.
Pedestrian Entry
Pedestrian Turnstile Gates
Speed gates, swing gates, flap barriers and tripod turnstiles. Designed for controlled, high-throughput pedestrian flow in lobbies, transit, campuses and factories.
Vehicle Entry
Vehicle Access Systems
Automatic barrier gates, LPR/ANPR, RFID vehicle access and smart parking management for car parks, yards and mixed-use sites.
Specification Matrix
Specs buyers need before committing
Typical configuration ranges across the product families. Final values are confirmed against your project drawings.
| Parameter | Pedestrian Turnstile Gates | Vehicle Access Systems |
|---|---|---|
| Lane / passage width | 550–900 mm per lane (custom widths on request) | Boom arm 3–8 m; lane width up to 6 m per barrier |
| Throughput | 20–60 passes per minute depending on model | 1–6 s open/close cycle; LPR release < 1 s |
| Primary materials | 304 / 316 stainless steel, tempered glass, acrylic | Steel boom, aluminium housing, IP-rated drive units |
| Control & readers | Card, fingerprint, face recognition, QR, RFID | LPR camera, RFID tag, push button, remote control |
| Integration protocols | RS485, TCP/IP, Wiegand, API | TCP/IP, RS485, REST API for parking platforms |
| Power supply | AC 110–240 V, 50/60 Hz | AC 110–240 V, 50/60 Hz, optional battery backup |
| Environmental rating | Indoor standard; IP54 outdoor options | IP54 and above for outdoor installation |
| Compliance | ISO9001 quality system, CE safety compliance |
Values shown are typical platform ranges. The exact figure for your site is confirmed against your drawings and the target destination environment during quotation.
Materials & Finishes
Built from materials that survive high traffic
Material selection is the first decision in any specification. We source stainless steel, glass and acrylic to the project requirement, and finish surfaces to match the building standard.
Stainless Steel
304 brushed standard; 316 for coastal and outdoor sites. Hairline, mirror or custom powder-coated finishes.
Tempered Glass
Swing gates and speed gates use 8–12 mm toughened glass for a transparent, premium lane.
Acrylic Panels
Lightweight, impact-resistant leaf and side panels for flap barriers and tripod enclosures.
Drive & Control
Servo and brushless motors, IR sensor arrays, and modular control boards for reliable cycling.
Customization Capability
Configured to the project, not the shelf
Every order is reviewed against your drawings. We adjust dimensions, materials, reader positions, finishes and integration logic before production begins.
| OEM / ODM | Branding, housing color, control board config |
|---|---|
| Custom dimensions | Lane width, housing size, boom length |
| MOQ | Project-based; confirmed per specification |
| Lead time | Confirmed at quote; staged shipping supported |
| Packaging | Export plywood crates, foam-protected, sea/air ready |
Quality Standards
QC checkpoints through production
Quality is checked at incoming material, assembly, and final burn-in before packing. See the full process on the factory page.
| Quality system | ISO9001 quality management system |
|---|---|
| Safety | CE EU safety compliance |
| Business profile | Dun & Bradstreet verified (637941335) |
| Final inspection | Function, sensor, and safety-cycle burn-in before export |
Built for Procurement Roles
Specified with your role in mind
For Procurement Managers
Price, MOQ and supplier reliability
- factory-direct pricing with project-based MOQ
- MOQ and lead time confirmed in writing
- quality-controlled production under ISO9001
For Project Managers
Drawings, installation and delivery
- drawing review before production begins
- installation guidance and staged shipping
- delivery coordinated to the handover date
Live Product Grid
Browse the current catalog
Product cards below load from the live catalog at runtime. See pedestrian gates and vehicle access systems for full line detail.
Products
FAQ
Common procurement questions
Yes. FlowGate Pro provides OEM and ODM access control manufacturing, including drawing-based customization, materials selection, and prototype development. Share your specifications for a tailored proposal.
What is your minimum order quantity (MOQ)?MOQ is project-based and depends on customization, materials, and target quantity. Send your requirements and we will confirm a workable MOQ and lead time.
Which certifications do you hold?Our access control production holds ISO9001 (quality management), CE (EU safety compliance), and Dun & Bradstreet (637941335). Certificates are available on request.
How can I request a quote?Submit your project details (product, quantity, destination, drawings) via the RFQ form and we will respond within one business day. Call +86 18127009316 or use the RFQ form on our Contact page.
Confirm product fit with a spec sheet
Tell us the entrance types, quantities and destination country. We will reply with the matching product specifications and pricing.
